SUNTAIL 550 EXPERIMENTAL LED POSITION & ANTI-COLLISION TAIL LIGHT

SUNTAIL 550 EXPERIMENTAL LED POSITION & ANTI-COLLISION TAIL LIGHT

The SunTail™ 550 EXP is the next-generation evolution of our trusted SunTail™ Position and Anti-Collision Tail Light—now featuring a slimmer profile, reduced weight, and enhanced performance.

Designed specifically for experimental aircraft, the SunTail 550 combines a powerful LED tail strobe and position light in one compact, energy-efficient unit. It integrates seamlessly with other AeroLEDs lighting systems and retrofits easily into existing legacy footprints—no external power supply required.

Key Features:

  • Dual Functionality: Strobe and position light.
  • Power Options: 14V and 28V compatible.
  • Energy Efficient: No external power supply required.
  • Easy Installation: Simple drop-in replacement. Horizontal mount option available for purchase separately.
  • Experimental

Part Numbers
View full details

EXPERIMENTAL - LED POSITION & ANTI-COLLISION TAIL LIGHT

Tech Specs

Cross Reference Chart

Documents

  • Current Draw:
    • 14VDC: Position Light: 0.33 Amps | Anti-Collision Light: .40 Amps (Average) | 2.35 Amps (Peak)
    • 28VDC: Position Light: 0.18 Amps | Anti-Collision Light: 0.21 Amps (Average) | 1.23 Amps (Peak)
  • Weight: 0.11 lbs.
  • Length: 2.2" Width: 1.7" Depth: 1"
Model Part # Description Approvals
SunTail 550- 14V - EXPERIMENTAL 01-1360-12

EXPERIMENTAL LED POSITION & ANTI-COLLISION TAIL LIGHT, 14 VDC
 None - Performance Meets TSO
SunTail 550 - 28V - EXPERIMENTAL  01-1360-24
EXPERIMENTAL LED POSITION & ANTI-COLLISION TAIL LIGHT, 28 VDC
 None - Performance Meets TSO
Legacy Product Part Number Legacy Part Model Number SunTail Part Number SunTail Model Number
01-0770024-00
A500AV14
01-1360-12
SunTail - 14V
01-0770024-01 A500AV28
01-1360-24
SunTail - 28V
01-0770034-00 A555AV14 01-1360-12 SunTail - 14V
01-0770034-01 A555AV28 01-1360-24 SunTail - 28V

NOTE: Any highlighted RED ITEMS will require extra wiring for Anti-Collision function of the SunTail™ series.

Tech Specs

  • Current Draw:
    • 14VDC: Position Light: 0.33 Amps | Anti-Collision Light: .40 Amps (Average) | 2.35 Amps (Peak)
    • 28VDC: Position Light: 0.18 Amps | Anti-Collision Light: 0.21 Amps (Average) | 1.23 Amps (Peak)
  • Weight: 0.11 lbs.
  • Length: 2.2" Width: 1.7" Depth: 1"
Model Part # Description Approvals
SunTail 550- 14V - EXPERIMENTAL 01-1360-12

EXPERIMENTAL LED POSITION & ANTI-COLLISION TAIL LIGHT, 14 VDC
 None - Performance Meets TSO
SunTail 550 - 28V - EXPERIMENTAL  01-1360-24
EXPERIMENTAL LED POSITION & ANTI-COLLISION TAIL LIGHT, 28 VDC
 None - Performance Meets TSO

Cross Reference Chart

Legacy Product Part Number Legacy Part Model Number SunTail Part Number SunTail Model Number
01-0770024-00
A500AV14
01-1360-12
SunTail - 14V
01-0770024-01 A500AV28
01-1360-24
SunTail - 28V
01-0770034-00 A555AV14 01-1360-12 SunTail - 14V
01-0770034-01 A555AV28 01-1360-24 SunTail - 28V

NOTE: Any highlighted RED ITEMS will require extra wiring for Anti-Collision function of the SunTail™ series.
