SUNSPOT 36 Equinox Dual-Function LED Landing & Taxi Light

SUNSPOT 36 Equinox Dual-Function LED Landing & Taxi Light

AeroLEDs SunSpot 36 Equinox is the industry’s first dual-function landing and taxi light, delivering tailored lighting for all phases of flight:

  • Landing Mode: Bright 20°x20° beam for enhanced visibility during high-speed takeoffs and landings.
  • Taxi Mode: Wide 20°x45° beam for superior runway/taxiway illumination without impairing other pilots’ vision.

With vivid, true-to-life illumination, the Equinox consumes less power, resists vibrations, and fits seamlessly into existing PAR36 mounts using a DPDT switch for dual-mode functionality.

Additional Features:

  • Built-in Pulse (wig-wag) mode for daytime recognition ,collision avoidance and reduced bird strikes.
  • Reduces electrical load by 50% in multi-light setups.

Specifications:

  • Power Consumption: 100 watts max
  • Lifespan: 30,000+ hours MTBF
  • Lens: UV-hardcoated polycarbonate
  • Construction: Aluminum, black powder-coated heat sink
  • Approvals: FAA-PMA/STC certified

Upgrade your aircraft lighting with the SunSpot 36 Equinox for unparalleled visibility, safety, and reliability.

Part Numbers
Contact Reseller
View full details

Equinox Dual-Function Landing & Taxi Light

Tech Specs

Documents

Video

  • Max Current: 14V: Landing: 7.1A Taxi: 5.4A 28V: Landing: 3.5A Taxi: 3.5A
  • Weight: 0.72 lbs.
  • Length: 4.4" Width: 4.4" Depth: 2.1"
Model Part # Description Candela Beam Profile Wigwag/Sync Approvals
36-Equinox - 14V 01-1030-LT-12 PAR 36 DUAL-FUNCATION LANDING & TAXI LIGHT 14V.


LANDING: 210,000

TAXI: 65,000

LANDING: 20ºx20º

TAXI: 20ºX45º

 Yes FAA-PMA/STC
36-Equinox- 28V 01-1030-LT-24 PAR 36 DUAL-FUNCTION LANDING & TAXI LIGHT 28V.



LANDING: 210,000

TAXI: 65,000



LANDING: 20ºx20º

TAXI: 20ºX45º

 Yes FAA-PMA/STC

Tech Specs

  • Max Current: 14V: Landing: 7.1A Taxi: 5.4A 28V: Landing: 3.5A Taxi: 3.5A
  • Weight: 0.72 lbs.
  • Length: 4.4" Width: 4.4" Depth: 2.1"
Model Part # Description Candela Beam Profile Wigwag/Sync Approvals
36-Equinox - 14V 01-1030-LT-12 PAR 36 DUAL-FUNCATION LANDING & TAXI LIGHT 14V.


LANDING: 210,000

TAXI: 65,000

LANDING: 20ºx20º

TAXI: 20ºX45º

 Yes FAA-PMA/STC
36-Equinox- 28V 01-1030-LT-24 PAR 36 DUAL-FUNCTION LANDING & TAXI LIGHT 28V.



LANDING: 210,000

TAXI: 65,000



LANDING: 20ºx20º

TAXI: 20ºX45º

 Yes FAA-PMA/STC

Documents

Video

WARNING: These products may contain chemicals known to the State of California to cause cancer and birth defects or other reproductive harm. For more information, visit aeroleds.com/regulatory.

Product Data Sheet
