AeroLEDs SunSpot Equinox is the industry’s first dual-function landing and taxi light, delivering tailored performance for any condition:

  • Landing Mode: Bright 20°x20° beam for enhanced visibility during high-speed takeoffs and landings.
  • Taxi Mode: Wide 20°x45° beam for superior runway and taxiway illumination without affecting other pilots’ vision.

These lights provide true-to-life color rendering, consume less power, and are resistant to vibrations, making them ideal for single or multi-light installations. Designed for convenience, the Equinox uses existing PAR46 mounts and requires only a DPDT switch for dual-mode functionality.

-H Model Features:

  • Built-in Pulse (wig-wag) mode for increased safety, aiding collision avoidance and reducing bird strikes.
  • Reduces electrical load by 50% in multi-light installations.

Specifications:

  • Power Consumption: 145/175 watts max
  • Lifespan: 30,000+ hours MTBF
  • Lens: UV-hardcoated polycarbonate
  • Construction: Aluminum, black powder-coated heat sink
  • Approvals: FAA-PMA/STC certified

Upgrade to SunSpot Equinox for unmatched versatility, visibility, and reliability in all your aircraft lighting needs.

Part Numbers
Contact Reseller
View full details

Equinox Dual-Function Landing & Taxi Light

Tech Specs

Documents

  • Max Current: Landing Light: 10.2A@14VDC, 6.3A@28VDC Taxi Light:  9.6A@14VDC, 6.3A@28VDC
  • Weight: 1.4 lbs.
  • Length: 5.6" Width: 5.6" Depth: 1.9"
Model Part # Description Candela/ Lumens Beam Profile Wigwag/Sync Approvals
46-Equinox-14V 01-2230-LT-12 PAR 46 DUAL-FUNCATION LANDING & TAXI LIGHT 14V.

CANDELA:

LANDING: 230,000

TAXI: 90,000

LUMENS: 15,000

LANDING: 20ºx20º

TAXI: 20ºX50º

 Yes FAA-PMA/STC
46-Equinox-28V 01-2230-LT-24 PAR 46 DUAL-FUNCATION LANDING & TAXI LIGHT 28V.



CANDELA:

LANDING: 300,00

TAXI: 120,000

LUMENS: 19,000



LANDING: 20ºx20º

TAXI: 20ºX50º

 Yes FAA-PMA/STC

Tech Specs

  • Max Current: Landing Light: 10.2A@14VDC, 6.3A@28VDC Taxi Light:  9.6A@14VDC, 6.3A@28VDC
  • Weight: 1.4 lbs.
  • Length: 5.6" Width: 5.6" Depth: 1.9"
Model Part # Description Candela/ Lumens Beam Profile Wigwag/Sync Approvals
46-Equinox-14V 01-2230-LT-12 PAR 46 DUAL-FUNCATION LANDING & TAXI LIGHT 14V.

CANDELA:

LANDING: 230,000

TAXI: 90,000

LUMENS: 15,000

LANDING: 20ºx20º

TAXI: 20ºX50º

 Yes FAA-PMA/STC
46-Equinox-28V 01-2230-LT-24 PAR 46 DUAL-FUNCATION LANDING & TAXI LIGHT 28V.



CANDELA:

LANDING: 300,00

TAXI: 120,000

LUMENS: 19,000



LANDING: 20ºx20º

TAXI: 20ºX50º

 Yes FAA-PMA/STC
