Pulsar 660 EXP LED FORWARD & TAIL POSITION/ANTI-COLLISION WINGTIP LIGHTS

Pulsar 660 EXP LED FORWARD & TAIL POSITION/ANTI-COLLISION WINGTIP LIGHTS

PULSAR™ 660 EXP (formerly Pulsar NSP Experimental) navigation LEDs deliver certified-level performance in a design tailored for Experimental and Light Sport Aircraft. Engineered to perform in the most demanding flight environments, they offer exceptional reliability and visibility in all conditions, with refined optics and an enhanced lens interface to support long-term durability.

 PULSAR™ 660 EXP PROVIDES THREE HIGH
PERFORMANCE FUNCTIONS:

 POSITION (Red | Green): Directional aviation red and green LEDs provide clear aircraft orientation for safe, compliant operation.

ANTI-COLLISION STROBE: High-intensity white strobe dramatically enhances aircraft visibility in both day and night operations, aiding in recognition and collision avoidance.

REAR POSITION (White): Aft-facing white light completes 360° coverage, improving visibility from all directions.

PULSAR™ 660 EXP is designed with an industry-standard three-position screw pattern and includes a mounting bracket, making them ideal for legacy light replacements. No external power supply is required, and the updated configuration maintains this footprint while incorporating improved internal architecture for long-term durability and stability.

FEATURES:

·      5 YEAR WARRANTY

·      HIGH-EFFICIENCY, LOW-POWER LEDS

·      LONG-LIFE, LOWMAINTENANCE DESIGN

·      SHOCK AND VIBRATION RESISTANT

·      BUILT-IN THERMAL PROTECTION

·      UV HARDCOATED POLYCARBONATE LENS

·      ALUMINUM CLEAR ANODIZED BASE

·      AeroLEDs STROBE SYNCHRONIZATION W/SunTail 550 EXP

·      AERODYNAMIC, LOW-DRAG PROFILE

Part Numbers
Contact Reseller
View full details





EXPERIMENTAL - LED FORWARD & TAIL POSITION/ANTI-COLLISION WINGTIP LIGHTS

Tech Specs

Documents

Video

  • Current Draw (ea):
    • 14VDC: Position Light: 0.8 Amps | Anti-Collision Light 0.8 Amps (Average) | 3.8 Amps (Peak)
    • 28VDC: Position Light: 0.4 Amps | Anti-Collision Light 0.4 Amps (Average) | 1.9 Amps (Peak)
  • Weight: 0.21 lbs.
  • Length: 4" Width: 1.9" Depth: 1.5"
  • Includes patented three-position mounting bracket
Model Part # Description Approvals
Pulsar 660 EXP - 14V RED

01-1380-C-12-L

01-1280-C-12-L (DISCONTINUED)
RED
EXPERIMENTAL FORWARD POS & WHITE TAIL POS LIGHT / ACL WINGTIP ASSEMBLY, 14 VDC.
  None
Pulsar 660 EXP - 14V GREEN

01-1380-C-12-R

01-1280-C-12-R (DISCONTINUED)
GREEN
EXPERIMENTAL FORWARD POS & WHITE TAIL POS LIGHT / ACL WINGTIP ASSEMBLY, 14 VDC.
  None
Pulsar 660 EXP - 28V RED

01-1380-C-24-L

01-1280-C-24-L (DISCONTINUED)
RED
EXPERIMENTAL FORWARD POS & WHITE TAIL POS LIGHT / ACL WINGTIP ASSEMBLY, 28 VDC.
  None
Pulsar 660 EXP - 28V GREEN

01-1380-C-24-R

01-1280-C-24-R (DISCONTINUED)
GREEN
EXPERIMENTAL FORWARD POS & WHITE TAIL POS LIGHT / ACL WINGTIP ASSEMBLY, 28 VDC.
  None

Tech Specs

  • Current Draw (ea):
    • 14VDC: Position Light: 0.8 Amps | Anti-Collision Light 0.8 Amps (Average) | 3.8 Amps (Peak)
    • 28VDC: Position Light: 0.4 Amps | Anti-Collision Light 0.4 Amps (Average) | 1.9 Amps (Peak)
  • Weight: 0.21 lbs.
  • Length: 4" Width: 1.9" Depth: 1.5"
  • Includes patented three-position mounting bracket
Model Part # Description Approvals
Pulsar 660 EXP - 14V RED

01-1380-C-12-L

01-1280-C-12-L (DISCONTINUED)
RED
EXPERIMENTAL FORWARD POS & WHITE TAIL POS LIGHT / ACL WINGTIP ASSEMBLY, 14 VDC.
  None
Pulsar 660 EXP - 14V GREEN

01-1380-C-12-R

01-1280-C-12-R (DISCONTINUED)
GREEN
EXPERIMENTAL FORWARD POS & WHITE TAIL POS LIGHT / ACL WINGTIP ASSEMBLY, 14 VDC.
  None
Pulsar 660 EXP - 28V RED

01-1380-C-24-L

01-1280-C-24-L (DISCONTINUED)
RED
EXPERIMENTAL FORWARD POS & WHITE TAIL POS LIGHT / ACL WINGTIP ASSEMBLY, 28 VDC.
  None
Pulsar 660 EXP - 28V GREEN

01-1380-C-24-R

01-1280-C-24-R (DISCONTINUED)
GREEN
EXPERIMENTAL FORWARD POS & WHITE TAIL POS LIGHT / ACL WINGTIP ASSEMBLY, 28 VDC.
  None
