The Pulsar 650 EXP (formally known as Pulsar NS)  is a versatile two-in-one lighting solution, combining a navigation light for directional red and green positioning and a strobe light for enhanced visibility during daylight and nighttime operations.

With its aerodynamic low-drag profile, industry-standard mounting footprint, and patented three-position mounting bracket, the Pulsar 650 EXP is perfect for replacing legacy light systems. The lights meet or exceed TSO C-30c (Type I, II) and C-96a (Class II) standards.

Key Features:

  • Dual Functionality: Navigation and strobe lighting in one compact unit.
  • Power Options: Compatible with 12V and 24V systems.
  • Energy Efficient: Low power consumption; no external power supply required.
  • Strobe Synchronization: Available for synchronized multi-light setups.
  • Easy Installation: Standard mounting design for seamless upgrades.
  • Category: For experimental aircraft.

Part Numbers
Contact Reseller
View full details

EXPERIMENTAL - LED FORWARD POSITION / ANTI-COLLISION WINGTIP LIGHTS

Tech Specs

Cross Reference Chart

Documents

Video

  • Max Current: 0.65A@14VDC(average) 4.9A@14VDC(peak), 0.4A@28VDC(average) 3.05A@28VDC(peak green), 3A@28VDC (peak red)
  • Weight: 0.24 lbs.
  • Length: 4" Width: 1.9" Depth: 1.5"
Model Part # Description Approvals
Pulsar 650 EXP - 14V RED 01-1280-B-12-L
RED
EXPERIMENTAL POSITION LIGHT / ANTI-COLLISION LIGHT WINGTIP ASSEMBLY, 14 VDC.
  None - Performance Exceeds TSO
Pulsar 650 EXP - 14V GREEN 01-1280-B-12-R
GREEN
EXPERIMENTAL POSITION LIGHT / ANTI-COLLISION LIGHT WINGTIP ASSEMBLY, 14 VDC.
  None - Performance Exceeds TSO
Pulsar 650 EXP - 28V RED 01-1280-B-24-L
RED
EXPERIMENTAL POSITION LIGHT / ANTI-COLLISION LIGHT WINGTIP ASSEMBLY, 28 VDC.
  None - Performance Exceeds TSO
Pulsar 650 EXP - 28V GREEN 01-1280-B-24-R
GREEN
EXPERIMENTAL POSITION LIGHT / ANTI-COLLISION LIGHT WINGTIP ASSEMBLY, 28 VDC.
  None - Performance Exceeds TSO
Legacy Product Part Number Legacy Product Model Number Pulsar™ 650 EXP Part Number Pulsar™ 650 EXP Model Number
01-0770054-01 A650PG28 01-1280-B-24-R Pulsar 650 EXP - 28V GREEN
01-0770054-03 A650PR28 01-1280-B-24-L Pulsar 650 EXP - 28V RED
01-0770054-00 A650PG14
 01-1280-B-12-R Pulsar 650 EXP - 14V GREEN
01-0770054-02 A650PR14 01-1280-B-12-L Pulsar 650 EXP - 14V RED
01-0771110-03 7111003 01-1280-B-24-L Pulsar 650 EXP - 28V RED
01-0771110-04 7111004
 01-1280-B-24-R
 Pulsar 650 EXP - 28V GREEN
01-0771110-01 7111001 01-1280-B-12-L Pulsar 650 EXP - 14V RED
01-0771110-02 7111002 01-1280-B-12-R Pulsar 650 EXP - 14V GREEN
01-0770001-42 W1285PG28 01-1280-B-24-R Pulsar 650 EXP - 28V GREEN
01-0770001-52 W1285PR28 01-1280-B-24-L Pulsar 650 EXP - 28V RED
01-0770001-41 W128514 01-1280-B-12-R Pulsar 650 EXP - 14V GREEN
01-0770001-51 W128514 01-1280-B-12-L Pulsar 650 EXP - 14V RED
01-0771105-03 7110503 01-1280-B-24-L Pulsar 650 EXP - 28V RED
01-0771105-04 7110504 01-1280-B-24-R Pulsar 650 EXP - 28V GREEN
01-0771105-01 7110501 01-1280-B-12-L Pulsar 650 EXP - 14V RED
01-0771105-02 7110502 01-1280-B-12-R Pulsar 650 EXP - 14V GREEN
NOTE: Any highlighted RED ITEMS will require extra wiring for anti-collision function of Pulsar™ Series.

Tech Specs

  • Max Current: 0.65A@14VDC(average) 4.9A@14VDC(peak), 0.4A@28VDC(average) 3.05A@28VDC(peak green), 3A@28VDC (peak red)
  • Weight: 0.24 lbs.
  • Length: 4" Width: 1.9" Depth: 1.5"
Model Part # Description Approvals
Pulsar 650 EXP - 14V RED 01-1280-B-12-L
RED
EXPERIMENTAL POSITION LIGHT / ANTI-COLLISION LIGHT WINGTIP ASSEMBLY, 14 VDC.
  None - Performance Exceeds TSO
Pulsar 650 EXP - 14V GREEN 01-1280-B-12-R
GREEN
EXPERIMENTAL POSITION LIGHT / ANTI-COLLISION LIGHT WINGTIP ASSEMBLY, 14 VDC.
  None - Performance Exceeds TSO
Pulsar 650 EXP - 28V RED 01-1280-B-24-L
RED
EXPERIMENTAL POSITION LIGHT / ANTI-COLLISION LIGHT WINGTIP ASSEMBLY, 28 VDC.
  None - Performance Exceeds TSO
Pulsar 650 EXP - 28V GREEN 01-1280-B-24-R
GREEN
EXPERIMENTAL POSITION LIGHT / ANTI-COLLISION LIGHT WINGTIP ASSEMBLY, 28 VDC.
  None - Performance Exceeds TSO

Cross Reference Chart

Legacy Product Part Number Legacy Product Model Number Pulsar™ 650 EXP Part Number Pulsar™ 650 EXP Model Number
01-0770054-01 A650PG28 01-1280-B-24-R Pulsar 650 EXP - 28V GREEN
01-0770054-03 A650PR28 01-1280-B-24-L Pulsar 650 EXP - 28V RED
01-0770054-00 A650PG14
 01-1280-B-12-R Pulsar 650 EXP - 14V GREEN
01-0770054-02 A650PR14 01-1280-B-12-L Pulsar 650 EXP - 14V RED
01-0771110-03 7111003 01-1280-B-24-L Pulsar 650 EXP - 28V RED
01-0771110-04 7111004
 01-1280-B-24-R
 Pulsar 650 EXP - 28V GREEN
01-0771110-01 7111001 01-1280-B-12-L Pulsar 650 EXP - 14V RED
01-0771110-02 7111002 01-1280-B-12-R Pulsar 650 EXP - 14V GREEN
01-0770001-42 W1285PG28 01-1280-B-24-R Pulsar 650 EXP - 28V GREEN
01-0770001-52 W1285PR28 01-1280-B-24-L Pulsar 650 EXP - 28V RED
01-0770001-41 W128514 01-1280-B-12-R Pulsar 650 EXP - 14V GREEN
01-0770001-51 W128514 01-1280-B-12-L Pulsar 650 EXP - 14V RED
01-0771105-03 7110503 01-1280-B-24-L Pulsar 650 EXP - 28V RED
01-0771105-04 7110504 01-1280-B-24-R Pulsar 650 EXP - 28V GREEN
01-0771105-01 7110501 01-1280-B-12-L Pulsar 650 EXP - 14V RED
01-0771105-02 7110502 01-1280-B-12-R Pulsar 650 EXP - 14V GREEN
NOTE: Any highlighted RED ITEMS will require extra wiring for anti-collision function of Pulsar™ Series.

Documents

Video

WARNING: These products may contain chemicals known to the State of California to cause cancer and birth defects or other reproductive harm. For more information, visit aeroleds.com/regulatory.

Product Data Sheet
